Steel Grades & Standards

  • Plain Carbon Structural Steels
  • Alloy Structural Steels
  • Bearing Steels
  • Spring Steels
  • Case Hardening Steels
  • Cold Heading Steels
  • Electrode Steels
  • Oil and Gas Steels

3SP Standard: GOST 380 Material Number: 1.0038
Equivalent Grades SAE/AISI DIN JIS GB
1018 RSt 37-2 SS330 GB/T Q235
Main Chemical Compostion(wt.%) C Si Mn P(max) S (max) Cr Mo Ni V Other
0.14-0.22 0.15-0.30 0.40-0.65 0.04 0.05 _ _ _ _ _
Type of Our Products Billet & Bloom

5SP Standard: GOST 380 Material Number: 1.0050
Equivalent Grades DIN JIS GB
St 50-2 SS500 GB/T Q275
Main Chemical Compostion(wt.%) C Si Mn P(max) S (max) Cr Mo Ni V Other
0.28-0.37 0.05-0.15 0.50-0.80 0.040 0.050 _ _ _ _ _
Type of Our Products Billet & Bloom

Q195 Standard: GB/T 700 Material Number: 1.0035
Equivalent Grades Afnor DIN Gost
A33 St33 St1SP
Main Chemical Compostion(wt.%) C(max) Si(max) Mn(max) P(max) S (max) Cr Mo Ni V Other
0.12 0.30 0.50 0.035 0.040 _ _ _ _ _
Type of Our Products Billet & Bloom, Wire Rod

Q235 Standard: GB/T 700 Material Number: 1.0036
Equivalent Grades Afnor DIN JIS
A34-2 St34-2 SS330
Main Chemical Compostion(wt.%) C(max) Si(max) Mn(max) P(max) S (max) Cr Mo Ni V Other
0.20 0.35 1.40 0.045 0.045 _ _ _ _ _
Type of Our Products Billet & Bloom, Wire Rod

ASTM A1006 Standard: ASTM A1006 Material Number: 1.0044
Equivalent Grades DIN SAE/AISI GB JIS UNS
St44-2 1020,1021 GB/T Q255A SS400 G10200
Main Chemical Compostion(wt.%) C(max) Si(max) Mn P(max) S (max) Cr Mo Ni V Other
0.22     0.025 0.015         _
Type of Our Products Billet & Bloom, Wire Rod

ASTM A1008 Standard: ASTM A1008 Material Number: 1.0044
Equivalent Grades DIN SAE/AISI GB JIS UNS
St44-2 1020,1021 GB/T Q255A SS400 G10200
Main Chemical Compostion(wt.%) C Si Mn(max) P(max) S(max) Cr(max) Mo(max) Ni(max) cu(max) Ti(max)
0.02-0.15 _ 0.60 0.025 0.035 0.15 0.06 0.20 0.20 0.025
Type of Our Products Billet & Bloom, Wire Rod

ASTM A1010 Standard: ASTM A1010 Material Number: 1.4512
Equivalent Grades DIN SAE/AISI AFNOR JIS UNS
X2CrTi12 409 Z3CT12 SUH409L S40900
Main Chemical Compostion(wt.%) C Si Mn P(max) S (max) Cr Mo Ni(max) N(max) Other
0.030 1.00 1.50 0.040 0.01 10.50-12.50 _ 1.50 0.03 _
Type of Our Products Billet & Bloom, Wire Rod

SWRH42B Standard: JIS G 3506 Material Number: 1.0511
Equivalent Grades DIN SAE/AISI GB UNS AFNOR
C40 1040 GB/T 40 G10400 C40
Main Chemical Compostion(wt.%) C Si Mn P(max) S (max) Cr(max) Ni(max) MO(max) CU(max) AI(max)
0.39-0.46 0.15-0.35 0.60-0.90 0.030 0.030 0.15 0.20 0.05 0.25 0.01
Type of Our Products Billet & Bloom, Wire Rod

SWRH52B Standard: JIS G 3506 Material Number: 1.0588
Equivalent Grades DIN SAE/AISI GB
D 53-2 C52D GB/T C52D
Main Chemical Compostion(wt.%) C Si Mn P(max) S (max) Cr(max) Ni(max) MO(max) CU(max) AI(max)
0.49-0.56 0.15-0.35 0.60-0.90 0.030 0.030 0.15 0.20 0.05 0.25 0.01
Type of Our Products Billet & Bloom, Wire Rod

SWRH62B Standard: JIS G 3506 Material Number: 1.0601
Equivalent Grades DIN SAE/AISI GB UNS AFNOR
C60 1060 GB/T 60 G10600 C60
Main Chemical Compostion(wt.%) C Si Mn P(max) S (max) Cr(max) Ni(max) MO(max) CU(max) AI(max)
0.59-0.66 0.15-0.35 0.60-0.90 0.030 0.030 0.15 0.20 0.05 0.25 0.01
Type of Our Products Billet & Bloom, Wire Rod

فولادهای ساده کربنی

SWRH67B Standard: JIS G 3506 Material Number: 1.0613
Equivalent Grades DIN SAE/AISI GB UNS AFNOR
D 68-2 1065 GB/T C68D G10650 C68D
Main Chemical Compostion(wt.%) C Si Mn P(max) S (max) Cr(max) Ni(max) MO(max) CU(max) AI(max)
0.64-0.71 0.15-0.35 0.60-0.90 0.030 0.030 0.15 0.20 0.05 0.25 0.01
Type of Our Products Billet & Bloom, Wire Rod

SWRH72B Standard: JIS G 3506 Material Number: 1.1231, 1.0603
Equivalent Grades DIN SAE/AISI GB UNS AFNOR
Ck67 1070 GB/T 65 G10700 C68
Main Chemical Compostion(wt.%) C Si Mn P(max) S (max) Cr(max) Ni(max) MO(max) CU(max) AI(max)
0.69-0.76 0.15-0.35 0.60-0.90 0.030 0.030 0.15 0.20 0.05 0.25 0.01
Type of Our Products Billet & Bloom, Wire Rod

SWRH82B Standard: JIS G 3506 Material Number: 1.0622
Equivalent Grades DIN SAE/AISI GB UNS AFNOR
D 80-2 1078 GB/T C80D G10780 C80D
Main Chemical Compostion(wt.%) C Si Mn P(max) S (max) Cr(max) Ni(max) MO(max) CU(max) AI(max)
0.79-0.86 0.15-0.35 0.60-0.90 0.030 0.030 0.15 0.20 0.05 0.25 0.01
Type of Our Products Billet & Bloom, Wire Rod
steel-Grades-Standards
steel-Grades-Standards
steel-Grades-Standards
steel-Grades-Standards
steel-Grades-Standards
steel-Grades-Standards
steel-Grades-Standards
steel-Grades-Standards

CK10 Standard: DIN 17210 Material Number: 1.1121
Equivalent Grades SAE/AISI GB JIS UNS UNI
1010 GB/T 10 S10C G10100 C10
Main Chemical Compostion(wt.%) C Si(max) Mn P(max) S(max) Cr Mo Ni V Other
0.07-0.13 0.40 0.30-0.60 0.035 0.035 _ _ _ _ _
Type of Our Products Rolled Billet, SBQ

CK15 Standard: DIN 17210 Material Number: 1.1141
Equivalent Grades SAE/AISI JIS UNS UNI GB
1015 S15C G10150 C16 GB/T 15
Main Chemical Compostion(wt.%) C Si(max) Mn P(max) S(max) Cr Mo Ni V Other
0.12-0.18 0.40 0.30-0.60 0.035 0.035 _ _ _ _ _
Type of Our Products Rolled Billet, SBQ

CK45 Standard: DIN 17200 Material Number: 1.1191
Equivalent Grades SAE/AISI UNI JIS UNS GB
1045 C45 S45C H10140,G10450 GB/T 45
Main Chemical Compostion(wt.%) C Si(max) Mn P(max) S(max) Cr Mo Ni V Other
0.42-0.50 0.40 0.50-0.80 0.035 0.03 _ _ _ _ _
Type of Our Products Rolled Billet, SBQ

GS-20Mn5 Standard: 17182 Material Number: 1.1120 (1.6220)
Equivalent Grades DIN EN JIS
G20Mn5 SCW480
Main Chemical Compostion(wt.%) C Si(max) Mn P(max) S(max) Cr(max) Mo(max) Ni(max) V Other
0.17-0.23 0.17-0.37 1.00-1.60 0.02 0.015 0.30 0.15 0.40 _ _
Type of Our Products Wire Rod

فولادهای سازه‌ای آلیاژی

30MnSi Standard: GB/T 24587 Material Number: _
Equivalent Grades

Main Chemical Compostion(wt.%) C Si Mn P(max) S(max) Ni(max) Cr(max) Cu(max) Mo Other
0.28-0.33 0.70-1.10 0.90-1.30 0.025 0.025 0.25 0.25 0.20 _ _
Type of Our Products Wire Rod

25CrMo4 Standard: DIN 17200 Material Number: 1.7218
Equivalent Grades SAE/AISI UNS JIS
4130 G41300 SCM420
Main Chemical Compostion(wt.%) C Si(max) Mn P(max) S(max) Cr Mo Ni V Other
0.22-0.29 0.40 0.60-0.90 0.035 0.03 0.90-1.20 0.15-0.30 _ _ _
Type of Our Products Rolled Billet, SBQ

42CrMo4 Standard: DIN 17200 Material Number: 1.7225
Equivalent Grades SAE/AISI GB JIS UNS
4140 GB/T 42CrMo SCM440 G41400
Main Chemical Compostion(wt.%) C Si(max) Mn P(max) S(max) Cr Mo Ni V Other
0.38-0.45 0.40 0.60-0.90 0.035 0.03 0.90-1.20 0.15-0.30 _ _ _
Type of Our Products Rolled Billet, SBQ, Wire Rod

20MnCr5 Standard: DIN 17210 Material Number: 1.7147
Equivalent Grades GB SAE/AISI JIS
20CrMnTi 5120H, 4820 SMnC420H
Main Chemical Compostion(wt.%) C Si(max) Mn Cr Ti Cu Mo Ni V Other
0.17-0.22 0.40 0.80-1.10 1.00-1.30 0.04-0.10 _ _ _ _ _
Type of Our Products Rolled Billet, SBQ

38MnB5 Standard: DIN 10083-3 Material Number: 1.5532
Equivalent Grades JIS
SWRCHB737
Main Chemical Compostion(wt.%) C Si(max) Mn P(max) S(max) B Cr Mo Other
0.36-0.40 0.40 1.15-1.45 0.025 0.035 0.0008-0.0050 _ _ _
Type of Our Products Rolled Billet, SBQ

فولادهای سازه‌ای آلیاژی

38MnVS6 Standard: DIN 10267 Material Number: 1.1303
Equivalent Grades Bsi DIN
BS 38MnVS6 1.5231
Main Chemical Compostion(wt.%) C Si(max) Mn P(max) S(max) N Cr(max) Mo V Other
0.34-0.41 0.15-0.80 1.20-1.60 0.025 0.020-0.060 0.010-0.020 0.30 0.08 0.08-0.20 _
Type of Our Products Rolled Billet, SBQ

30CrNiMo8 Standard: DIN 17200 Material Number: 1.658
Equivalent Grades SAE/AISI Bsi
4340 BS 823M30
Main Chemical Compostion(wt.%) C Si(max) Mn P(max) S(max) Cr Mo Ni V Other
0.26-0.34 0.40 0.30-0.60 0.035 0.03 1.80-2.20 0.30-0.50 1.80-2.20 _ _
Type of Our Products Rolled Billet, SBQ
steel-Grades-Standards
steel-Grades-Standards
steel-Grades-Standards
steel-Grades-Standards
steel-Grades-Standardsا
steel-Grades-Standards
steel-Grades-Standards
steel-Grades-Standards

100Cr6 Standard: DIN 17230 Material Number: 1.3505
Equivalent Grades SAE/AISI GB
52100 GB/T B00150
Main Chemical Compostion(wt.%) C Si(max) Mn P(max) S(max) Cr Ni(max) Cu(max) Mo Other
0.90-1.05 0.15-0.35 0.25-0.45 0.030 0.025 1.35-1.65 0.30 0.30 _ _
Type of Our Products SBQ, Wire Rod

100CrMo7 Standard: DIN 17230 Material Number: 1.3537
Equivalent Grades JIS
100CrMo7
Main Chemical Compostion(wt.%) C Si(max) Mn P(max) S(max) Cr Ni(max) Cu(max) Mo Other
0.90-1.05 0.20-0.40 0.25-0.45 0.030 0.025 1.65-1.95 0.15-0.25 0.30 0.30 _
Type of Our Products SBQ
steel-Grades-Standards
steel-Grades-Standards
steel-Grades-Standards
steel-Grades-Standards
steel-Grades-Standards
steel-Grades-Standards
steel-Grades-Standards
steel-Grades-Standards

CK55 Standard: DIN 17200 Material Number: 1.1203
Equivalent Grades SAE/AISI GB JIS
1055 GB 55 S55C
Main Chemical Compostion(wt.%) C Si(max) Mn P(max) S(max) Cr Mo Ni V Other
0.52-0.60 0.40 0.60-0.90 0.045 0.045 _ _ _ _ _
Type of Our Products SBQ, Rolled Billet

CK60 Standard: DIN 17200 Material Number: 1.1221
Equivalent Grades SAE/AISI GB JIS
1060, 1064 GB/T 60 S58C
Main Chemical Compostion(wt.%) C Si(max) Mn P(max) S(max) Cr Mo Ni V Other
0.57-0.65 0.4 0.60-0.90 0.035 0.03 _ _ _ _ _
Type of Our Products SBQ, Rolled Billet

CK75 Standard: DIN 17222 Material Number: 1.1248
Equivalent Grades SAE/AISI GB JIS
1070, 1075 GB/T 75 S75CM
Main Chemical Compostion(wt.%) C Si(max) Mn P(max) S(max) Cr Mo Ni V Other
0.70-0.80 0.15-0.35 0.60-0.80 0.035 0.035 _ _ _ _ _
Type of Our Products SBQ, Rolled Billet

55Cr3 Standard: DIN EN 10089 Material Number: 1.7176
Equivalent Grades SAE/AISI GB JIS
5155, 5160 GB/T 60CrMnA JIS SUP9
Main Chemical Compostion(wt.%) C Si(max) Mn P(max) S(max) Cr Mo Ni V Other
0.52-0.59 0.40 0.70-1.00 0.025 0.025 0.70-1.00 _ _ _ _
Type of Our Products SBQ

51CrV4 Standard: DIN EN 10089 Material Number: 1.8159
Equivalent Grades SAE/AISI GB JIS
6150 55CrVA SUP10
Main Chemical Compostion(wt.%) C Si(max) Mn P(max) S(max) Cr Mo Ni V Other
0.47-0.55 0.40 0.70-1.10 0.025 0.025 0.90-1.20 _ _ 0.10-0.25 _
Type of Our Products SBQ

52CrMoV4 Standard: DIN EN 10089 Material Number: 1.7701
Equivalent Grades SAE/AISI AFNOR
4150 51CDV4
Main Chemical Compostion(wt.%) C Si(max) Mn P(max) S(max) Cr Mo Ni V Other
0.48-0.56 0.40 0.70-1.10 0.025 0.025 0.90-1.20 0.15-0.30 _ 0.10-0.20 _
Type of Our Products SBQ

54SiCr6 Standard: DIN EN 10089 Material Number: 1.8159
Equivalent Grades cen
EN 1.8152
Main Chemical Compostion(wt.%) C Si(max) Mn P(max) S(max) Cr Mo Ni V Other
0.51-0.59 1.20-1.60 0.50-0.80 0.025 0.025 0.50-0.80 _ _ _ _
Type of Our Products Wire Rod

60SiCr7 Standard: DIN 17221 Material Number: 1.7108
Equivalent Grades DIN EN SAE/AISI cen
61SiCr7 9260 EN 61SiCr7
Main Chemical Compostion(wt.%) C Si(max) Mn P(max) S(max) Cr Mo V
0.55-0.65 1.50-1.80 0.70-1.00 0.025 0.025 0.20-0.40 _ _
Type of Our Products SBQ

38Si7 Standard: DIN EN 10089 Material Number: 1.5023
Equivalent Grades cen
EN 38Si7
Main Chemical Compostion(wt.%) C Si Mn P(max) S(max) Cr Mo Ni V Other
0.35-0.42 1.50-1.80 0.50-0.80 0.025 0.025 _ _ _ _ _
Type of Our Products SBQ
steel-Grades-Standards
steel-Grades-Standards
steel-Grades-Standards
steel-Grades-Standards
steel-Grades-Standards
steel-Grades-Standards
steel-Grades-Standards
steel-Grades-Standards

18CrNi8 Standard: DIN 17210 Material Number: 1.592
Equivalent Grades cen
EN 18CrNi8
Main Chemical Compostion(wt.%) C Si Mn P(max) S(max) Cr Mo(max) Ni V Other
0.15-0.22 0.17-0.37 0.40-0.70 0.035 0.035 1.80-2.10 0.10 1.80-2.10 _ _
Type of Our Products Rolled Billet, SBQ

34CrNiMo6 Standard: DIN EN 10083 Material Number: 1.6582
Equivalent Grades SAE/AISI Bsi JIS
4340 BS 817M40 SNCM447
Main Chemical Compostion(wt.%) C Si(max) Mn P(max) S(max) Cr Mo Ni V Other
0.30-0.38 0.40 0.50-0.80 0.035 0.035 1.30-1.70 0.15-0.30 1.30-1.70 _ _
Type of Our Products Rolled Billet, SBQ

18CrNiMo7-6 Standard: DIN EN 10084 Material Number: 1.6587
Equivalent Grades SAE/AISI Bsi JIS DIN
4820 18CrNiMo7-6 18CrNiMo7-6 17CrNiMo6
Main Chemical Compostion(wt.%) C Si(max) Mn P(max) S(max) Cr Mo Ni V Other
0.15-0.21 0.40 0.50-0.90 0.035 0.035 1.50-1.80 0.25-0.35 1.40-1.70 _ _
Type of Our Products Rolled Billet, SBQ

27MnCrB5-2 Standard: DIN EN 10083 Material Number: 1.7182
Equivalent Grades

Main Chemical Compostion(wt.%) C Si(max) Mn P(max) S(max) Cr Mo Ni B
0.24-0.30 0.40 1.10-1.40 0.035 0.040 0.30-0.60 _ _ 0.0008-0.0050
Type of Our Products Rolled Billet, SBQ

16MnCr5 Standard: DIN EN 10084 Material Number: 1.7131
Equivalent Grades SAE/AISI Bsi JIS
5115 BS 527M20 SCR415
Main Chemical Compostion(wt.%) C Si(max) Mn P(max) S(max) Cr Mo Ni V Other
0.14-0.19 0.40 1.00-1.30 0.035 0.035 0.80-1.10 _ _ _ _
Type of Our Products Rolled Billet
steel-Grades-Standards
steel-Grades-Standards
steel-Grades-Standards
steel-Grades-Standards
steel-Grades-Standards
steel-Grades-Standards
steel-Grades-Standards
steel-Grades-Standards

33B2 Standard: DIN EN 10263 Material Number: 1.5514
Equivalent Grades cen
EN 33B2
Main Chemical Compostion(wt.%) C Si(max) Mn P(max) S(max) Cr(max) Cu(max) Mo B
0.30-0.35 0.30 0.60-0.90 0.025 0.025 0.30 0.25 _ 0.0008-0.005
Type of Our Products SBQ

30MnB4 Standard: DIN EN 10263 Material Number: 1.5526
Equivalent Grades SAE/AISI GB JIS
Main Chemical Compostion(wt.%) C Si(max) Mn P(max) S(max) Cr Mo Cu(max) B
0.27-0.32 0.30 0.80-1.10 0.025 0.025 0.30 _ 0.25 0.0008-0.005
Type of Our Products SBQ

31CrMoB2-1 Standard: DIN EN 10263 Material Number: 1.7272
Equivalent Grades cen
EN 31CrMoB2-1
Main Chemical Compostion(wt.%) C Si(max) Mn P(max) S(max) Cr Mo Cu(max) B
0.28-0.33 0.30 0.90-1.20 0.025 0.025 0.40-0.55 0.10-0.15 0.25 0.0008-0.005
Type of Our Products SBQ

C10C Standard: DIN EN 10263 Material Number: 1.0214
Equivalent Grades SAE/AISI DIN JIS GB
1012 QSt 36-3 SWCH10 GB/T ML10Al
Main Chemical Compostion(wt.%) C Si(max) Mn P(max) S(max) Cr Mo Ni Al
0.08-0.12 0.10 0.30-0.50 0.025 0.025 _ _ _ 0.020-0.060
Type of Our Products SBQ

C15C Standard: DIN EN 10263 Material Number: 1.0234
Equivalent Grades JIS DIN
SWRCH15A QSt 38-3
Main Chemical Compostion(wt.%) C Si(max) Mn P(max) S(max) Cr Mo Ni Al
0.13-0.17 0.10 0.35-0.60 0.025 0.025 _ _ _ 0.020-0.060
Type of Our Products SBQ

C20C Standard: DIN EN 10263 Material Number: 1.0411
Equivalent Grades cen
EN 1.0411
Main Chemical Compostion(wt.%) C Si(max) Mn P(max) S(max) Cr Mo Ni Al
0.18-0.22 0.10 0.70-0.90 0.025 0.025 _ _ _ 0.020-0.060
Type of Our Products SBQ

SAE10B21 Standard: SAE J403 Material Number: 1.0044
Equivalent Grades DIN GB AFNOR
St44-2 GB/T Q255A S275JR
Main Chemical Compostion(wt.%) C Si Mn P(max) S(max) Cr Mo Ni B
0.18-0.23 _ 0.60-0.90 0.030 0.050 _ _ _ 0.005-0.003
Type of Our Products SBQ, Wire Rod

SAE10B35 Standard: SAE J403 Material Number: 1.0516
Equivalent Grades DIN GB AFNOR
D 35-2 GB/T C38D C38D
Main Chemical Compostion(wt.%) C Si Mn P(max) S(max) Cr Mo Ni B
0.32-0.38 _ 0.60-0.90 0.030 0.050 _ _ _ 0.005-0.003
Type of Our Products SBQ, Wire Rod

SAE10B38 Standard: SAE J403 Material Number: 1.115
Equivalent Grades DIN GB JIS
C38D2 GB/T C38D2 S35CM
Main Chemical Compostion(wt.%) C Si Mn P(max) S(max) Cr Mo Ni B
0.35-0.42 _ 0.60-0.90 0.030 0.050 _ _ _ 0.005-0.003
Type of Our Products SBQ, Wire Rod
steel-Grades-Standards
steel-Grades-Standards
steel-Grades-Standards
steel-Grades-Standards
steel-Grades-Standards
steel-Grades-Standards
steel-Grades-Standards
steel-Grades-Standards

RST34 Standard: DIN 17100 Material Number: 1.0034
Equivalent Grades GB
Q215
Main Chemical Compostion(wt.%) C Si Mn P(max) S(max) Cr Mo Ni V Other
0.11-0.16 0.04-0.07 0.50-0.80 0.05 0.05 0.010-0.014 _ _ _ _
Type of Our Products Billet & Bloom, Wire Rod

SG2 Standard: DIN 8559 Material Number: -
Main Chemical Compostion(wt.%) C Si (max) Mn P(max) S(max) Cr(max) Mo Ni(max) Cu(max) Other
0.06-0.13 0.70-1.00 1.30-1.060 0.025 0.025 0.15 - 0.15 0.3 -
Type of Our Products Billet & Bloom, Wire Rod

SG3 Standard: DIN 8559 Material Number: -
Main Chemical Compostion(wt.%) C Si (max) Mn P(max) S(max) Cr(max) Mo Ni(max) Cu(max) Other
0.06-0.13 0.80-1.20 1.60-1.90 0.025 0.025 0.15 - 0.15 0.3 -
Type of Our Products Wire Rod

SWRY11 Standard: JIS G 3503 Material Number: 1.0204
Equivalent Grades SAE/AISI DIN UNS
1008 C11G1C G10080
Main Chemical Compostion(wt.%) C(max) Si(max) Mn P(max) S(max) Cr Mo Ni V +Nb + Ti(max)
0.09 0.03 0.35-0.65 0.02 0.023 - _ _ 0.15
Type of Our Products Wire Rod
steel-Grades-Standards
steel-Grades-Standards
steel-Grades-Standards
steel-Grades-Standards
steel-Grades-Standards
steel-Grades-Standards
steel-Grades-Standards
steel-Grades-Standards

X52 Standard: API 5L Material Number: -
Equivalent Grades API 5L GB JIS
L360
Main Chemical Compostion(wt.%) C(max) Si Mn(max) P(max) S(max) Cr Mo Ni V +Nb + Ti(max)
0.28 - 1.4 0.03 0.03 _ _ _ 0.15
Type of Our Products Billet & Bloom

L80 Standard: API 5CT Material Number: -
Equivalent Grades Type C(max) Si(max) Mn P(max) S(max) Cr Mo Ni(max) Cu(max)
1 0.43 0.45 max 1.90 0.03 0.03 - - 0.25 0.35
9Cr 0.15 1 0.30-0.60 0.02 0.01 8.00-10.00 0.90-1.10 0.5 0.25
Type of Our Products Billet & Bloom

P110 Standard: API 5CT Material Number: -
Equivalent Grades C Si(max) Mn P(max) S(max) Cr Mo Ni V Other
- - - 0.03 0.03 - - - - -
Type of Our Products Billet & Bloom

C110 Standard: API 5CT Material Number: -
Main Chemical Compostion(wt.%) C(max) Si(max) Mn(max) P(max) S(max) Cr Mo Ni(max) Cu Other
0.35 - - 0.02 0.005 0.40-1.50 0.25-1.00 0.99 - -
Type of Our Products Billet & Bloom



steel-Grades-Standards
